Datalogic PowerScan M8300 User Manual

REFERENCES
167
These default values are always
2
restored through the reading of RS-232 or WEDGE
interface selection code, see chapter .
For the WEDGE interface, the following extended keyboard values can also be
configured:
EXTENDED KEYBOARD TO HEX CONVERSION TABLE
IBM AT
IBM 3153
APPLE ADB
IBM XT IBM 31xx, 32xx,
34xx, 37xx
Wyse
Digital
HEX KEY KEY KEY KEY
83
ENTER
ENTER
FIELD EXIT
RETURN
84
TAB
TAB
TAB
TAB
85
F1 F1 F1 F1
86
F2
F2
F2
F2
87
F3
F3
F3
F3
88
F4
F4
F4
F4
89
F5
F5
F5
F5
8A
F6
F6
F6
F6
8B
F7
F7
F7
F7
8C
F8
F8
F8
F8
8D
F9
F9
F9
F9
8E
F10
F10
F10
F10
8F
F11
ESC
F11
F11
90
F12
BACKSPACE
F12
F12
91
HOME
HOME
ENTER
F13
92
END
END
RESET
F14
93
PG UP
PG UP
INSERT
F15
94
PG DOWN
PG DOWN
DELETE
F16
95
↑ ↑
FIELD - UP
96
↓ ↓
FIELD +
DOWN
97
← ←
ENTER (Paddle)
LEFT
98
→ →
PRINT RIGHT
99
ESC
ESC
ESC
9A
CTRL (Right)
CTRL (Right)
CTRL (Right)
9B
Euro
Space
Space
Space
For all devices using I
BM AT (compatible) Wedge or USB-KBD
C
interfaces, all values from 9C to
FE send the relative simulated keypress when available or else the relative ALT-Mode
sequence. See the Hex to Character Conversion Table in Appendix .
For all devices using other Wedge interfaces, all values from 9C to FE send the Space
character.

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
