Datalogic PowerScan M8300 User Manual

POWERSCAN
®
D8330/M8300/M8300-DK
228
DISPLAY PARAMETERS 16-Keys (Continued)
QTY Field
Transmit code with dafault QTY
Bh0
Transmit code alone
Bh1
Discard barcode, generate error beep
Bh2
QTY/CODE send mode
QTY precedes CODE
Bg0
CODE precedes QTY
Bg1
Code sent out
Bg2
RepeatTimeout
Bitt
QTY/CODE separator no terminator
EW0
one character
EW1b
two characters
EW2bb
three characters
EW3bbb
four characters
EW4bbbb
five characters
EW5bbbbb
six characters
EW6bbbbbb
seven characters
EW7bbbbbbb
eight characters
EW8bbbbbbbb
Append Code
Overwrite CODE and transmit
Bm0
Append to CODE and transmit
Bm1
Append to code, don’t transmit
Bm2
ddmmyy = numbers from the Hex/Numeric Table representing day, month, year
hhmm = numbers from the Hex/Numeric Table representing hour, minutes
a = a number from the Hex/Numeric Table
b = HEX values representing an ASCII character
c = a number from the Hex/Numeric Table in range [1..5] representing the
Function Key identifier
x = a number from the Hex/Numeric Table in range [0..A] representing the
CMD_ID identifier
t = a number in the range 00-99 (sec.) from the Hex/Numeric Table
00 = Timeout disabled (always on).
b = 3 Hex values from 00 to FE representing the left, centre and right keys.
FF = KeyID disabled.

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
