POWERSCAN
®
D8330/M8300/M8300-DK
28
5.
Set Radio Address
ÌRA0RFHÎ
+
four digits for the PowerScan
®
M8300 Address (from 0000 to 1999).
All readers used in the same area must have different addresses.
6.
Exit and Save Configuration
Ì$-?Î
7.
Read the
Bind
code to pair the PowerScan
®
M8300 to the BC-80X0 cradle.
The reader is dedicated to the cradle. Any previously bound
reader will be
excluded.
To connect several readers to the same cradle see the following paragraph
4.5.1, ‘Using Multiple M8300 Series Readers with Same Cradle'.
Bind
Ì$+RN0$-IÎ
The green LED on the PowerScan
®
M8300 will blink; the reader is ready to be
inserted into the cradle.
8.
Firmly insert the reader into the BC-80X0 cradle within 10 seconds, a beep will
be emitted, signaling that the BC-
80X0 cradle has been paired to the
PowerScan
®
M8300, and the green LED on the reader will go off.
green LED

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
