Datalogic PowerScan M8300 User Manual

WEDGE
57
Some ASCII characters may be missing as this depends on the type of keyboard: these are
generally particular characters relative to the various national symbologies. In this case:
• The first 4 characters (Shift, Alt, Ctrl, and Backspace) can only be substituted with
keys not used, or substituted with each other.
• characters can be substituted with other single symbols (e.g. "SPACE") even if not
included in the barcode set used.
• characters can be substituted with others corresponding to your keyboard.
The device signals the end of the procedure with 2 beeps indicating the keys have been
registered.
01 : Shift
02 : Alt
03 : Ctrl
04 :
Backspace
05 : SPACE
28 : 7
51 : N
06 : !
29 : 8
52 : O
07 : "
30 : 9
53 : P
08 : #
31 : :
54 : Q
09 : $
32 : ;
55 : R
10 : %
33 : <
56 : S
11 : &
34 : =
57 : T
12 : '
35 : >
58 : U
13 : (
36 : ?
59 : V
14 :
)
37 :
@
60 :
W
15 : *
38 : A
61 : X
16 : +
39 : B
62 : Y
17 : ,
40 : C
63 : Z
18 : -
41 : D
64 : [
19 : .
42 : E
65 : \
20 : /
43 : F
66 : ]
21 : 0
44 : G
67 : ^
22 : 1
45 : H
68 : _ (underscore)
23 : 2
46 : I
69 : `
24 :
3
47 :
J
70 :
{
25 : 4
48 : K
71 : |
26 : 5
49 : L
72 : }
27 :
6
50 :
M
73 :
~
74 : DEL
Do not place the reader onto the BC-80X0 cradle during this procedure.
Otherwise, the battery charging will occur modifying the LEDs functioning.
CAUTION

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
