Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 97
(SP) Serial Port – This command configures the serial communication port(s) as
follows:
Table 5-12: Serial Port Configuration Set Command
For EX2 models the data length, parity, and stop bits are fixed at 8, N, and 1
respectively. And, for Applicator Interface Card-equipped models, this command is
also used to configure the GPIO Auxiliary port (ID always “B”).
Example: <STX>KcSPAPB;SPApN;SPAD8;SPAS1;SPAB19<CR>
The example above configures Serial Port A to use hardware and software
handshaking, an eight-bit word, with no parity and one stop bit at 19,200 bits per
second.
Value Serial Port Range / Interpretation
xyz
Where: x = Port Identifier:
y = Function: z = Setting
P - Handshaking
Protocol
B - both
H - hardware
N - none
S – software
p - Parity E - even
N - none
O – odd
D - Data Length 7 - eight bits
8 - seven bits
A - Serial A
B - Serial B
S - Stop Bits 1 - one bit
2 - two bits
xyzz
Where: x = Port Identifier:
y = Function: zz = Setting:
A - Serial A
B - Serial B
B - Baud Rate 12 - 1200
24 - 2400
48 - 4800
96 - 9600
19 - 19200
28 - 28800
38 - 38400
57 - 57600
15 - 115200
To Next Page
