Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 77
802.3 – Wired Ethernet Configuration Parameters – Identifier ‘WE’
The ‘WE’ sub-group contains network configuration parameters that apply only to the
Wired Ethernet (802.3 Specification) ethernet interface. No sub-groups are currently
defined for the ‘WE’ sub-group of configuration parameters, only item-value pairs.
The ‘Item-Value’ pairs within the ‘WE’ sub-group are defined by the following table:
Item
Number
Name Available
to User
(Y/N)
Value Type Description
1 DHCP Enable Y Boolean Indicates if the DHCP Protocol is to
be used to automatically obtain all
required network addresses.
Formally known as IP Discovery.
2 Static Printer IP
Address
Y String Static IP Address for the Printer in
dotted decimal notation.
3 Static Printer
Subnet Mask
Y String Static Subnet Mask for the Printer in
dotted decimal notation.
4 Static Printer
Default Gateway or
Router
Y String Static Default Gateway (Router) IP
Address in dotted decimal notation.
5 PHY Mode Y Decimal Defines the ethernet PHY Mode
(Auto, 10BaseT HD, etc.)
Auto-Negotiate = 0
10BaseT Half Duplex = 1
10BaseT Full Duplex = 2
100BaseT Half Duplex = 3
100BaseT Full Duplex = 4
6 PHY Advertise Mode Y Decimal Defines the ethernet PHY Advertise
mode.
Auto = 0
All Capabilities = 1
7 PHY Capabilities to
Advertise
Y Decimal Defines the ethernet PHY capabilities
to advertise.
Always = 0
8 MTU Y Decimal Defines the Maximum Transmission
Unit size for the wired interface.
Defaults to the DEFAULT MTU from
the ‘G’ sub-group.
802.11 – Wireless Ethernet - WIFI Configuration Parameters – Identifier ‘WIFI’
The ‘WIFI’ sub-group contains network configuration parameters that apply only to the Wireless Ethernet
(802.11 Specification) ethernet interface. Four (4) sub-groups are currently defined for the ‘WIFI’ sub-
group of configuration parameters and are as follows:
General WIFI Configuration Parameters – Identifier ‘G’
DPAC Version 1 – Identifier ‘DV1’
DPAC Version 2 (Veyron) – Identifier ‘DV2’
SILEX Version 1 – Identifier ‘SV1’
