Extended System-Level Command Functions
78 Class Series 2 Programmer’s Manual
General WIFI Configuration Parameters – Identifier ‘G’
The ‘G’ WIFI sub-group contains the configuration parameters that are generally common to ALL WIFI
radio modules used by Datamax-O’Neil. These configuration parameters are universally standard within
the WIFI realm and are interpreted commonly by the various WIFI radio modules. The ‘Item-Value’ pairs
within the ‘G’ sub-group of the ‘WIFI’ sub-group are defined by the following table:
Item
Number
Name Available
to User
(Y/N)
Value Type Description
1 DHCP Enable Y Boolean Indicates if the DHCP Protocol is to
be used to automatically obtain all
required network addresses.
Formally known as IP Discovery.
2 Static Printer IP
Address
Y String Static IP Address for the Printer in
dotted decimal notation.
3 Static Printer
Subnet Mask
Y String Static Subnet Mask for the Printer in
dotted decimal notation.
4 Static Printer
Default Gateway or
Router
Y String Static Default Gateway (Router) IP
Address in dotted decimal notation.
5 MTU Y Decimal Defines the Maximum Transmission
Unit size for the wired interface.
Defaults to the DEFAULT MTU from
the ‘G’ sub-group. Cannot exceed
the maximum ethernet packet size!!!
6 Ad-Hoc Channel Y Decimal WIFI Channel Number used when
operating in Peer-Peer (Ad-Hoc)
mode.
7 Region Code Y String Two (2) character zero terminate
Region Code string, such as “US”.
8 WEP Key Used Y Decimal A decimal number from 1 to 4 that
designates the WEP key used.
9 WEP Key 1 Y String 10 or 26 digit WEP Key 1
10 WEP Key 2 Y String 10 or 26 digit WEP Key 2
11 WEP Key 3 Y String 10 or 26 digit WEP Key 3
12 WEP Key 4 Y String 10 or 26 digit WEP Key 4
13 Pre-Shared Key or
PSK
Y String 8 to 64 character Pre-Shared Key
used by WPA-PSK or WPA2-PSK
14 LEAP Used ID Y String User ID String for LEAP (Cisco) EAP
Protocol.
15 LEAP Password Y String Password String for LEAP (Cisco) EAP
Protocol.
16 EAP User ID Y String User ID String for other EAP
Protocols.
17 EAP Password Y String Password String for other EAP
Protocols
18 EAP Realm Y String Realm String for EAP Protocols that
utilize a Realm.
19 SSID Y String String that represents the SSID if in
Infrastructure mode.
20 WIFI Type Y Decimal WIFI Module type (DPAC1=1,
SILEX=2, DPAC2=3)
