Extended System-Level Command Functions
80 Class Series 2 Programmer’s Manual
DPAC Version 2 WIFI Configuration Parameters – Identifier ‘DV2’
The ‘DV2’ WIFI sub-group contains the configuration parameters that are specific to
the DPAC Version 2 (Veyron) WIFI radio module used by Datamax-O’Neil. The ‘Item-
Value’ pairs within the ‘DV2’ sub-group of the ‘WIFI’ sub-group are defined by the
following table:
Item
Number
Name Available
to User
(Y/N)
Value Type Description
1 Network Type Y Decimal Value that represents a Valid
Network Type for the DPAC Version 2
module.
AD-HOC = 0
Infrastructure = 1
2 WIFI Security Type Y Decimal Value that represents the DPAC
Version 2 Security Codes supported.
Security Disabled = 0
WEP, 64 Bit Key = 1
WEP, 128 Bit Key = 2
WPA-PSK = 3
WPA CISCO LEAP = 4
TKIP+40Bit WEP using EAP (LEAP) = 5
TKIP+128Bit WEP using EAP (LEAP) = 6
TKIP+40Bit WEP using WPA-PSK = 7
TKIP+128Bit WEP using WPA-PSK = 8
WPA2-PSK = 9
WPA/WPA2 TLS = 10
WPA/WPA2 PEAP = 11
WPA/WPA2 TTLS = 12
3 WIFI Authentication
Type
Y Decimal Value that represents the DPAC
Version 2 Authentication Types
supported (Auto, Open, Shared
Key, EAP, etc.).
Automatic = 0
Open = 1
Shared Key = 2
