6/ Repair Procedures
1503-0151-000 5/26/0 6-25
Prepare power module for removal
1. Threaded holes for mounting screws (item 5) to mount the power cord bracket.
2. Power cord fuse block
3. Power cord securing bracket
4. Lock washers No. 4 external
5. Bracket mounting screws 4x8 mm button/socket head
Figure 6-20
Power cord removal
