7/ Illustrated Parts List
7-6 1503-0151-000 3/27/97
1. Mounting shelf locating pins for anesthesia system, 1503-5013-000
2. Power cord fuse block, 1503-3020-000. See figure 7-11
3. Power cord receptacle, see Figure 7-11
4. Power cord bracket, 1503-3070-000
5. Bracket mounting screws, 0140-6226-118 (2), lockwashers 9213-0540-003 (2)
6. Threaded hole for shipping screw
7. Locking knob, 1301-3018-000
8. Deflector tube for free breathing valve, 1503-3110-000
9. Power cord (not shown)
ANSI - 1503-3078-000
IEC - 1503-3079-000
REV IEC - 1503-3080-000
Figure 7-9
Chassis bottom view
