7/ Illustrated Parts List
7-2 1503-0151-000 3/27/97
1. Screw M4, 0140-6226-111 (4)
2. Label set, 1503-3027-000 (includes fuse label on bottom chassis)
Figure 7-1
Top cover
1. Washer, 9213-0540-003
2. Ground wire, 1500-7037-000
3. Hex nut, 0144-3717-314,
4. Top cover, 1503-3031-000
Figure 7-2
Top cover ground wire connections
1
2
2
