Datex-Ohmeda 7900 - Figure 7-16 Manifold Components

7/ Illustrated Parts List
7-10 1503-0151-000 3/27/97
1. Drive gas check valve assembly 1503-3006-000
2. O-ring - 1503-3057-000
3. Flow control valve, 1503-8013-000
4. Regulator, 1503-3004-000
Figure 7-16
Manifold components
1. O-rings, 1503-3056-000 (6)
2. O-ring, 0210-0538-300 (1)
Figure 7-17
Pneumatic manifold O-rings
1
2
3
4
