15. Install the MOBO housing cover.
16. Reinstall the bellows and ABA pop-off valve, the ABA housing and remove all
occlusions.
1. MOBO installation alignment tool
2. Cover mounting screws, 4x8 mm
3. Top cover, no-pilot weight cylinder
4. No-pilot weight cylinder
5. Captive MOBO assembly mounting screws
6. MOBO assembly body
7. Port for no-pilot weight
8. Port with O-ring
9. Port for pilot weight diaphragm
10 7900 main manifold
Figure 6-31
MOBO alignment and installation
