7/ Illustrated Parts List
1503-0151-000 3/27/97 7-15
1. Diaphragm assembly, 1503-3000-000
2. Exhalation valve assembly, 1503-3001-000
3. Exhalation valve kit (not shown) includes 2 diaphragms, 2 o-rings, gasket and
manifold assembly,1503-8004-000
Figure 7-24
Exhalation manifold valve, see O&M Manual
Figure 7-25
SIB (Sensor interface board) assembly, 1503-8009-000
