DayTronic System 10 - 1.E.2 Connection and Setup of Analog Input Cards and Accessories

The following System 10-compatible Conditioner Cards are treated in
this section:
• Model 10A9-8C Eight-Channel Thermocouple Conditioner
• Model 10A10-4 Quad Isolated Thermocouple Conditioner
• Model 10A15-8 Eight-Channel Thermistor Conditioner
• Model 10A16-4C Quad Platinum RTD Conditioner
• Model 10A17-2 Dual High-Voltage Isolation RTD Conditioner
• Model 10A18-4C Quad 100-Ohm Platinum Linear RTD Conditioner
• Model 10A30-2C Dual LVDT Conditioner
• Model 10A31-4 Quad LVDT Conditioner
• Model 10A35 Encoder Conditioner
• Model 10A40 Frequency Input Conditioner
• Model 10A41-2C Dual Frequency Input Conditioner
• Model 10A43 Dwell Angle Conditioner
• Model 10A45 Simmonds Shaft Torque Sensor Conditioner
• Model 10A48 Modulated Carrier Flow Conditioner
• Model 10A60-4 Quad Voltage Conditioner
• Model 10A61-2 Dual 4-20 mA Input Conditioner
• Model 10A62-8C Eight-Channel 4-20 mA Conditioner
• Model 10A63-2 Dual Voltage Conditioner
• Model 10A64-8C Eight-Channel Voltage Conditioner
• Model 10A65-8 Eight-Channel Low-Level Voltage Conditioner
• Model 10A68-2 Dual AC RMS Conditioner
• Model 10A69-4 Quad AC RMS Conditioner
• Model 10A70-2 Dual Strain Gage Conditioner
• Model 10A72-2C Enhanced Dual Strain Gage Conditioner
• Model 10A73-4 Quad 1/2 & 1/4 Bridge Strain Gage Conditioner
• Model 10A74-4C Quad Strain Gage Track-Hold Conditioner
(cont’d)
SYSTEM 10 ANALOG INPUT CARDS 1.E.2
SYSTEM 10 GUIDEBOOK
CONNECTION AND SETUP OF
ANALOG INPUT CARDS AND ACCESSORIES
