DayTronic System 10 - 1.d If You Need Help...; 2 Physical Layout

HAS BEEN PROPERLY ESTABLISHED. For “remote” command entry, the easy-to-
use
TERMINAL program is included in the StartPAC V software supplied with
your mainframe—although any conventional terminal emulation package will also
work.
1.d IF YOU NEED HELP…
If at any time you need assistance in getting your System 10 “on the air”—or if
problems arise at any later time—feel free to call our CUSTOMER SERVICES
DEPARTMENT at
(937) 293-2566
FAX: (937) 293-2586
TOLL-FREE: (800) 668-4745
during normal business hours (Monday through Friday, 8:00 a.m. to 5:00 p.m.).
Or you can EMAIL us at
sales@daytronic.com
2 PHYSICAL LAYOUT
DO NOT PLUG IN YOUR MAINFRAME JUST YET.
Remove your mainframe’s front bezel(s). For each bezel, pull down the two
“swell-latch” levers and then pull the bezel forward. The upper bezel must be off
in order for you to access your mainframe’s EEPROM Write Protect Switch and
RS-232 PROTOCOL SWITCHES.
Study the appropriate front- and rear-view drawings below to familiarize yourself
with your mainframe’s most important physical elements. Be sure that you know
the locations of your particular mainframe’s
•
B Rack and B Cards, including Central Processor Card and Interface Card
(internal)
•
V Cards, including Video Signal Card and Video Text Card (internal)
•
A Rack(s), A Slots, and A Cards (internal)
•
System Status Indicators (visible from the front)
•
ON/OFF Button (front or rear panel)
•
Power Connector and Fuse/Circuit Breaker (rear panel)
•
Plug-In Keyboard Connector (front panel)
•
Computer Interface Connector (rear panel)
•
RS-232 Protocol Switches (internal)
•
EEPROM Write Protect Switch (internal)
•
Power Selector Board (rear panel, Models 10KN3, 10KN6, and 10KN7)
•
CRT Controls (internal, Models 10KN7 and 10KN8A)
•
VGA Input Connector (rear panel, Models 10KN3, 10KN6, and 10KN8A)
•
VGA Output Connector (rear panel, Models 10KN3, 10KN6, and 10KN8A)
•
“RGB” and RS-170 Output Connectors (rear panel, Model 10KN7)
•
RS-232 Formatted Output Connector (rear panel, active only if a Model
10VFO132 card is present)
Shown in Fig. 2.3 is the Extended Keyboard you will use to set up your system.
B - 3
PHYSICAL LAYOUT
“O NTHE A IR ” (B-S IZED )
