DayTronic System 10 - Appendix A: Summary of A-Sized Mainframe Features

APPENDIX A
SUMMARY OF A-SIZED MAINFRAME FEATURES
Max. No.
Analog Max. No
Available Channels
1
/ Logic Bits /
A-Card Max. No. Max.No Data Display Available
Model Slots Analog I/O
2
Logic I/O
3
and Keyboard/Keypad Options*
10KU 4 160 / 32 1000 / 64 OPTIONAL front-panel keypad S, V
with 2-line “billboard” LCD (
10DISU);
OPTIONAL remote multichannel
VFD display with keyboard (
10VFD-2);
OPTIONAL extended or operator’s
keyboard with 2-line “billboard” LCD
(
10P80D or 10P25D)
10KU-KD 4 160 / 32 1000 / 64 Integral front-panel keypad with S, V
2-line “billboard” LCD;
OPTIONAL extended or operator’s
keyboard with or without 2-line
“billboard” LCD (
10P80D, 10P80A,
(
10P25D, or 10P25A)
10K1C 20 160 / 160 1000 / 320 OPTIONAL front-panel multichannel S
VFD display with keyboard (
10VFD);
OPTIONAL remote multichannel
VFD display with keyboard (
10VFD-2);
OPTIONAL extended or operator’s
keyboard with 2-line “billboard” LCD
(
10P80D or 10P25D)
10K2D 20 160 / 160 1000 / 320 Integral front-panel multichannel VFD —
display; extended keyboard (
10P80A)
supplied; operator’s keyboard (
10P25A)
OPTIONAL
4
10K4TA 10 160 / 80 1000 / 160 OPTIONAL front-panel keypad V
with 2-line “billboard” LCD (
10DIS4T);
OPTIONAL remote multichannel
VFD display with keyboard (
10VFD-2);
OPTIONAL extended or operator’s
keyboard with 2-line “billboard” LCD
(
10P80D or 10P25D)
(cont’d)
A - 30
SUMMARY OF A-SIZED MAINFRAME FEATURES
* Options:
S = Satellite (required for Model 10BD4-based networks)
V = Vehicle Operation (12 or 28 V-DC)
1
Up to 1000 channels can be handled when the “S” (Satellite) Option is present.
2
Assumes all A SLOTS dedicated to analog I/O only (with eight channels per slot).
3
Assumes all A SLOTS dedicated to logic I/O only; requires one optional Model 10AIO-16 Universal Logic
I/O Card for every group of 16 bits to serve as logic I/O.
4
The Model 10P80D or 10P25D keyboard may NOT be used with this mainframe.
