Table 1 10A60-4 “Type” Codes
Full-Scale Channel
Range Type Code
±0.5 V-DC 5A
±1.0 V-DC 5B
±2.0 V-DC 5C
±5.0 V-DC 5D
±10.0 V-DC 5E
±20.0 V-DC 5F
2 TRANSDUCER CONNECTIONS
The Model 10A60-4’s I/O CONNECTOR mates with Daytronic CONDITIONER CON-
NECTOR No. 60322, shown in Fig. 1.5 (in Manual Section 1.E.1). Table 2 gives stan-
dard pin assignments for the I/O Connector.
Cabling for
floating inputs is given in Fig. 1(a). NOTE: To minimize signal noise, it is
recommended that for a floating (ungrounded) input with high common-mode imped-
ance, the COMMON pin be tied to the –SIGNAL line at the connector. Cabling for
grounded inputs is shown in Fig. 1(b).
Table 2 Model 10A60-4 Pin Assignments
I/O Connector Conditioner Conditioner
Pin Channel Line
Number Number Function
11+SIGNAL
A1–SIGNAL
21COMMON
B Not Committed
32+SIGNAL
C2–SIGNAL
42COMMON
D Not Committed
53+SIGNAL
E3–SIGNAL
63COMMON
F Not Committed
74+SIGNAL
H4–SIGNAL
84COMMON
J Not Committed
9,K,10,L Not Committed
10A60-4.2 TRANSDUCER CONNECTIONS
10A60-4 QUAD DC VOLTAGE CARD
