Table 1 10A65-8 “Type” Codes
Full-Scale Channel
Range Type Code
±50 mV-DC 61
±100 mV-DC 60
±200 mV-DC 62
2 TRANSDUCER CONNECTIONS
The Model 10A65-8’s I/O CONNECTOR mates with Daytronic CONDITIONER CON-
NECTOR No. 60322, shown in Fig. 1.5 (in Manual Section 1.E.1). Table 2 gives stan-
dard pin assignments for the I/O Connector.
Note that
floating (ungrounded) inputs are to be grounded at the site of the signal
source
, and not at the CONDITIONER CONNECTOR.
Table 2 Model 10A65-8 Pin Assignments
I/O Connector Conditioner Conditioner
Pin Channel Line
Number Number Function
11+SIGNAL
A1–SIGNAL
22+SIGNAL
B2–SIGNAL
33+SIGNAL
C3–SIGNAL
44+SIGNAL
D4–SIGNAL
55+SIGNAL
E5–SIGNAL
66+SIGNAL
F6–SIGNAL
77+SIGNAL
H7–SIGNAL
88+SIGNAL
J8–SIGNAL
9,K COMMON
10,L Not Committed
10A65-8.2 TRANSDUCER CONNECTIONS
10A65-8 EIGHT-CHANNEL LOW-LEVEL DC VOLTAGE CARD
