18
FURTHER OPTIONAL PROCEDURES
In this booklet we have taken you step-by-step through some important Sys-
tem 10 setup procedures that apply to “A-sized” mainframes. We have also
briefly mentioned a number of other (essentially optional) procedures
detailed in the
System 10 Guidebook. To these we could add the following:
setup of COUNTER/TIMER functions when the optional Model 10ACT01
Counter/Timer Card
and/or Model 10ACC-4 Four-Channel Totalizer
Card
is present (Section 3.A.1 of the System 10 Guidebook)
setup of ANALOG OUTPUT CHANNELS via the ANALOG OUTPUT (ANO)
command when the optional Model 10AAO-8 Voltage Output Card is
present, (Section 3.A.2)
setup of DIGITAL I/O functions when the optional
Model 10AIO-16 Univer-
sal Logic I/O Card
is present (Section 3.A.3)
setup of ANALOG PEAK CAPTURE, “MAX MINUS MIN,” and/or TRACK
AND HOLD functions when the optional
Model 10A79-4 Four-Channel
Analog Peak Capture Card
is present (Sections 3.A.4-6)
setup of ANALOG BUFFERING functions when the optional Model
10A79-4 Four-Channel Analog Peak Capture Card
or Model 10AAO-4
Analog Buffer Card
is present (Section 3.A.7)
setup of BUFFER STORAGE functions when the optional Model 10AFIFO
First-In-First-Out Buffer Memory Card
is present (Section 3.A.8)
setup of PID LOOP CONTROL functions when the optional Model 10APID
Loop Control Card
is present (Section 3.A.9)
setup and use of optional DIAGNOSTIC CARDS: Model 10AST Analog
Slot Test Card
and Model 10AHM Health Monitor Card (Section 5.C)
A - 29
FURTHER OPTIONAL PROCEDURES
“O
NTHE
A
IR
(A-S
IZED
)
To minimize the danger of losing critical setup infor-
mation in the event of a power interruption, be sure to
turn the EEPROM Switch OFF as soon as System 10
setup is complete.
