5.C OPTIONAL DIAGNOSTIC TOOLS
1. Model 10AEX-20 "A Card" Extender Board
2. Model 10AST Analog Slot Test Card
a. Model 10AST Test points
b. Displaying Test Signals as Data Channels
3. Models 10AHM and 10BDHM Health Monitor Cards
a. Introduction
b. Installation and Configuration
c. 10AHM/10BDHM Subchannels
APPENDICES
[A] SYSTEM 10 DATA SHEET
[NOTE: This section will be included within the Guidebook
itself only when a
printed version is supplied.]
[B] [NOTE: This appendix has been superseded by the current
Guidebook
Section 1.B (“Card Insertion and Removal”),
and has been removed.]
CDATA-CHANNEL RECONFIGURATION: TYP, LCT,
AND RST COMMANDS
1. Uses of the RESET (RST) Command
2. Data-Channel Reconfiguration
3. System 10 Channel TYPE Codes
[D] [NOTE: This appendix has been superseded by material in
the current Guidebook
Section 1.A.3.a (“Mainframe
Powerup, AC Operation”)
, and has been removed.]
E"REBOOTING" THE SYSTEM
HLINEARIZATION TECHNIQUES
L.1 BINARY TRANSMISSION MNEMONICS
1. The DUMP SYSTEM DATA (DSD) Command
2. The
DUMP SYSTEM FIELD DATA (DSF) Command
3. The
DUMP SYSTEM BIT DATA (DSB) Command
4. The
DUMP SYSTEM MESSAGE (DSM) Command
NPER-CHANNEL PROCESSING SPEEDS
1. Introduction
2. Overview of the 10BCP200 Scan Cycle
3. Comparison of "System 10" and "System 10/2000" Processing Speed
4. Calculation of Scan Rate
