DayTronic System 10 - Page 65

Max. No.
Analog Max. No
Available Channels
1
/ Logic Bits /
A-Card Max. No. Max.No Data Display Available
Model Slots Analog I/O
2
Logic I/O
3
and Keyboard/Keypad Options*
10K4T-KD 10 160 / 80 1000 / 160 Integral front-panel keypad with S, V
2-line “billboard” LCD;
OPTIONAL extended or operator’s
keyboard with or without 2-line
“billboard” LCD (
10P80D, 10P80A,
(
10P25D, or 10P25A)
10K4T-DA 10 160 / 80 1000 / 160 Integral front-panel multichannel VFD —
display; extended keyboard (
10P80A)
supplied; operator’s keyboard (
10P25A)
OPTIONAL
4, 5
A - 31
SUMMARY OF A-SIZED MAINFRAME FEATURES
* Options:
S = Satellite (required for Model 10BD4-based networks)
V = Vehicle Operation (12 or 28 V-DC)
1
Up to 1000 channels can be handled when the “S” (Satellite) Option is present.
2
Assumes all A SLOTS dedicated to analog I/O only (with eight channels per slot).
3
Assumes all A SLOTS dedicated to logic I/O only; requires one optional Model 10AIO-16 Universal Logic
I/O Card for every group of 16 bits to serve as logic I/O.
4
The Model 10P80D or 10P25D keyboard may NOT be used with this mainframe.
5
The front bezel of the Model 10K4T-DA may itself be used as a remote VFD display (up to 25 ft.), if an option-
al remote power supply (available from Daytronic) is provided.
“O NTHE A IR ” (A-S IZED )
