DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
50 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
Timer settings Value
Start delay
#
5s
Pre-heat
#
0s
Cranking time
#
10s
Crank rest time
#
10s
Smoke limit 0s
Smoke limit off 0s
Safety on delay
#
10s
Overspeed overshoot
#
2s
Warming up time
#
0s
Breaker close pulse 0.5s
Breaker trip pulse 0.5s
Return delay
#
30s
Cooling time
#
1m
ETS solenoid hold 0s
Fail to stop delay
#
30s
Generator transient delay
#
0s
Battery low volts delay
#
1m
Battery high volts delay
#
1m
LCD page timer 5m
Generator settings – Voltage/frequency Trip Return
Under volts trip
#
184V AC N/A
Under volts pre-alarm
#
196V AC 207V AC
Over volts pre-alarm
#
265V AC 253V AC
Over volts trip
#
276V AC N/A
Under frequency trip
#
40.0Hz N/A
Under frequency pre-alarm
#
42.0Hz 45.0Hz
Over frequency pre-alarm
#
55.0Hz 52.0Hz
Over frequency trip
#
57.0Hz N/A
Droop
#
Disabled N/A
Droop %
#
0.0% N/A
Loading Voltage
207V Ph-N
Loading Frequency
45.0 Hz
Alternative voltage
#
230v norm / 115v alt Disabled on module
Alternative Frequency
#
50Hz norm / 60Hz alt Disabled on module
Generator settings – Current/power Value
Generator CT primary 600A
Generator CT secondary 5A
CT location Generator only
Generator full load rating
#
500 A
Delayed overcurrent
#
100% ( 500A )
Trip Curve 36
Engine settings – Crank disconnect Value
Crank disconnect on generator frequency 21.0Hz
Crank disconnect oil pressure <Disabled>
Check oil pressure prior to starting Yes
Engine settings – speed Value
Underspeed trip
#
1250 RPM Disabled
Underspeed prealarm
#
1350 RPM Disabled
Overspeed prealarm
#
1650 RPM Disabled
Overspeed trip
#
1750 RPM Disabled
Overspeed overshoot
#
0% Disabled
