Defender SENTINEL 3 User Manual

SENTINEL 3 5
1. WHAT IS INCLUDED
2. BUTTON FUNCTIONS AND CONNECTIONS
2.1 FRONT PANEL
1. LED Indicators (Alarm/Play/HDD/Record)
2. Removable/Lockable HDD Casing: 3.5” IDE HDD
3. Camera Channel Select (1-8)
4. Record Button
5. Stop Button
6. Play Button
7. Pause Button
8. Split Button – Switch between Full Screen/ Quad Screen/ 9-Split Screen
9. Auto Sequencing Button – Automatically cycle through all the camera
channels
10. Search Button – Quickly search your recorded footage by date and event.
11. Menu Button
12. Exit/Info Button – Return to the previous menu/view system information
Software CD10 RCA to BNC
Connectors
1 Remote Control for
LCD Monitor
10ft RJ45
Ethernet Cable
8” Ultra Slim LCD
Monitor
8 Camera Mounts w/
Hardware
8 Indoor/Outdoor Night
Vision CCD Cameras
1 DVR (250GB HDD)
•1 Power Adapter for LCD Monitor
•1 Power Adapter for DVR
•Online/ Toll Free Support
•1 10ft RCA to RCA
(male) A/V Wire
1 RCA Female to
3.5mm (male)
A/V Wire
8 x 60ft 4 PIN DIN to
RCA (male)Video/
Power Wires
•Instruction Manual
•Quick Start Guide
•1 Year Warranty
•8 Power Adapters for Cameras

Defender SENTINEL 3 Specifications

General

Brand	Defender
Model	SENTINEL 3
Category	Security System
Language	English
