Option E2
GOV/AVR or transducer output card.
Term. Function Description
65 Not used
66 0 to 20 mA out Speed governor/AVR set point output or transducer
(Analogue output 66)
67 0
68 Not used
69 Not used
70 0 to 20 mA out Speed governor/AVR voltage set point output or transducer
(Analogue output 70)
71 0
72 Not used
Option EF2
GOV/AVR or transducer output card.
Term. Function Description
65 Not used
66 +/-20 mA Speed governor/AVR set point output or transducer
(Analogue output 66)
67 0
68 Not used
69 Not used
70 0(4) to 20 mA out Speed governor/AVR set point output or transducer
(Analogue output 70)
71 0
72 Not used
Option EF4
GOV/AVR or transducer combination output card.
Term. Function Description
65 ANA + Speed governor/AVR set point output or transducer
(Analogue output 66)
66 ANA -
67 Not used
68 Not used
69 Relay 69
250 V AC, 8 A
GOV/AVR control or configurable
70
71 Relay 71
250 V AC, 8 A
GOV/AVR control or configurable
72
