Deif GPU-3 Hydro Installation Instructions

Option EF5
PWM GOV and AVR combination output card.
Term. Function Description
65 +/-25 mA out AVR set point output
66 0
67 PWM + PWM speed governor signal
68 PWM -
69 Relay 69
250 V AC, 8 A
GOV/AVR control or configurable
70
71 Relay 71
250 V AC, 8 A
GOV/AVR control or configurable
72
Option EF6
PWM GOV and AVR combination output card.
Term. Function Description
65 Not used
66 Not used
67 0 Speed governor, AVR or transducer output 68
68 +/-25 mA out
69 PWM + PWM speed governor signal
70 PWM -
71 0 Speed governor, AVR or transducer output 72
72 +/-25 mA out
Option EF6 is not available for PPU.
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 32 of 64
