Deif GPU-3 Hydro Installation Instructions

Response
times
(Delay set to
min.)
Busbar:
Over-/under-voltage: <50 ms
Over-/under-frequency: <50 ms
Voltage unbalance: <200 ms
Generator:
Reverse power: <200 ms
Over-current: <200 ms
Fast over-current: <40 ms
Over-/under-voltage: <200 ms
Over-/under-frequency: <300 ms
Overload: <200 ms
Current unbalance: <200 ms
Voltage unbalance: <200 ms
React. power import: <200 ms
React. power export: <200 ms
Overspeed: <400 ms
Digital inputs: <250 ms
Emergency stop: <200 ms
Multi-inputs: <800 ms
Wire failure: <600 ms
Mains:
df/dt (ROCOF): <130 ms (4 periods)
Vector jump: <40 ms
Positive sequence: <60 ms
Time-dependent under-volt-
age, U
t
<
<50 ms
Under-voltage and reactive
power low, U
Q
<
<250 ms
Mounting DIN-rail mount or base mount with six screws
Safety To EN 61010-1, installation category (over-voltage category) III, 600 V, pollution degree 2
To UL 508 and CSA 22.2 no. 14-05, over-voltage category III, 600 V, pollution degree 2
EMC/CE GPC-3 and GPU-3: To EN 61000-6-2, EN 61000-6-4, IEC 60255-26.
PPU-3: To EN 61000-6-2, EN 61000-6-4, IEC 60255-26. IEC 60533 Power distribution
zone, IACS UR E10 Power distribution zone
Vibration 3 to 13.2 Hz: 2 mm
pp
. 13.2 to 100 Hz: 0.7 g. To IEC 60068-2-6 & IACS UR E10
10 to 60 Hz: 0.15 mm
pp
. 60 to 150 Hz: 1 g. To IEC 60255-21-1 Response (class 2)
10 to 150 Hz: 2 g. To IEC 60255-21-1 Endurance (class 2)
Shock
(base
mount)
10 g, 11 ms, half sine. To IEC 60255-21-2 Response (class 2)
30 g, 11 ms, half sine. To IEC 60255-21-2 Endurance (class 2)
50 g, 11 ms, half sine. To IEC 60068-2-27
Bump 20 g, 16 ms, half sine. To IEC 60255-21-2 (class 2)
Material All plastic materials are self-extinguishing according to UL94 (V1)
ML-2 installation instructions 4189340582
UK
Technical information
DEIF A/S Page 63 of 64
