Plug con-
nections
Tightening
torque
AC current: 0.2 to 4.0 mm
2
stranded wire. (UL/cUL Listed: AWG 18)
AC voltage: 0.2 to 2.5 mm
2
stranded wire. (UL/cUL Listed: AWG 20)
Relays: (UL/cUL Listed: AWG 22)
Terminals 98 to 116: 0.2 to 1.5 mm
2
stranded wire. (UL/cUL Listed: AWG 24)
Other: 0.2 to 2.5 mm
2
stranded wire. (UL/cUL Listed: AWG 24)
Display: 9-pole Sub-D female
Service port: USB A-B
See chapter Mounting and dimensions
Protection Unit: IP20. Display: IP40 (IP54 with gasket: option L). (UL/cUL Listed: Type Complete De-
vice, Open Type). To IEC/EN 60529
Governors Multi-line 2 interfaces to all governors including GAC, Barber-Colman, Woodward and Cum-
mins. See interfacing guide at www.deif.com
Approvals Marine-approved by all major classification societies
UL/cUL Listed to UL508. UL/cUL Recognized to UL2200
UL mark-
ings
Tightening
torque
Wiring: use 60/75 °C copper conductors only
Mounting: for use on a flat surface of type 1 enclosure
Installation: to be installed in accordance with the NEC (US) or the CEC (Canada)
AOP-2:
Maximum ambient temperature: 60 °C
Wiring: use 60/75 °C copper conductors only
Mounting: for use on a flat surface of type 3 (IP54) enclosure. Main disconnect must be pro-
vided by installer
Installation: to be installed in accordance with the NEC (US) or the CEC (Canada)
DC/DC converter for AOP-2:
Wire size: AWG 22-14
See chapter Mounting and dimensions
Weight Base unit: 1.6 kg (3.5 lbs.)
Option J1/J3/J6: 0.2 kg (0.4 lbs.)
Option J2: 0.4 kg (0.9 lbs.)
Display: 0.4 kg (0.9 lbs.)
ML-2 installation instructions 4189340582
UK
Technical information
DEIF A/S Page 64 of 64
