Delios DLS 300 - Page 8

8
Cod.: 240.010.0042
DLS / DLS-C Series
Fig. 02_A
2 3 41
2 3 41
2 3 41
2 3 41
1 - DC switch
2 - AC GRID circuit breaker
3 - AC OUT circuit breaker
4 - AC BYPASS switch
Fig. 02_B
1 - DC switch
2 - AC GRID circuit breaker
3 - AC OUT circuit breaker
4 - AC BYPASS switch
