DLS / DLS-C Series
9
Cod.: 240.010.0042
Fig. 03_A
21 3 4 5 6 7 89
1 - Battery input
2 - Battery temperature sensor
3 - External wiring
4 - PV1 string input
5 - PV2 string input
6 - Public AC grid output
7 - Public AC grid input
8 - Home loads AC output
9 - LAN connector
Fig. 03_B
3 4 5 6 7 8219
1 - Battery input
2 - Battery temperature sensor
3 - PV1 string input
4 - PV2 string input
5 - External wiring
6 - Public AC grid output
7 - Public AC grid input
8 - Home loads AC output
9 - LAN connector
