Installing Printer Drivers on the Windows Computers 103
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_SFP_UG_FM\Mioga_SFP_UG_FM\section10.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
D:\Drivers\XPS\Win_7Vista\XPS_2150.zip (where D is the
CD drive letter)
2 Click Start  Devices and Printers .
3 Click Add a printer .
4 Click Add a network , wireless or Bluetooth printer .
5 Select printer or click The printer that I want isn't listed .
When you select your printer, go to step 8.
When you click
The printer that I want isn't listed , go to step 6.
6 Select Add a printer using a TCP/IP address or host name , and then click
Next .
7 Select TCP/IP Device from Device type , and enter the IP address for
Hostname or IP address , and then click Next .
If the
User Account Control dialog box appears, click Ye s .
NOTE: If you are an administrator on the computer, click Ye s; otherwise,
contact your administrator to continue the desired action.
8 Click Have Disk to display the Install From Disk dialog box.
9 Click Browse , and then select the extracted folder in step 1.
10 Click OK .
11 Select your printer name and click Next .
12 To change the printer name, enter the printer name in the Printer name box,
and then click
Next .
To use this printer as the default printer, select the
Set as the default printer
check box.
13 If you do not share your printer, select Do not share this printer . If you
share your printer, select
Share this printer so that others on your network
can find and use it
.
14 Click Next .
Installation starts.
15 As the driver installation is completed, click Print a test page to print a test
page.
16 Click Finish .

Dell 2150cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Processor frequency	400 MHz
Maximum internal memory	750 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Network ready	-
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compatible operating systems	Microsoft Windows 7/Vista/2008/XP/2003 Mac OS: 10.3.9+/10.4.11+/10.5/10.6 Linux: SUSE Linux 10/Red Hat Linux 5
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 412.8 mm
