NOTICE: To avoid irregular screen image or malfunctioning of your printer,
avoid placing the printer in direct sunlight with the single sheet feeder opened.
Rear View
Space Requirements
Provide enough room to open the printer trays, covers, and optional accessories,
and for proper ventilation.
5 Belt Unit 10 Front Cover
NOTE: You can open the front cover by
pushing the side button (2).
1 Power Switch 6 Wireless Adapter Socket
2 Power Connector 7 Memory Slot
3 Tray Rear Cover 8 Control Board
4 Ethernet Port 9 Control Board Cover
5 USB Port
