Dell Printer Configuration Web Tool 141

Dell Printer Configuration Web Tool

Overview

NOTE: This web tool is not available unless the printer is connected to a network

using a network cable or the wireless printer adapter.

NOTE: The images used and procedures described in this manual are those of

Dell

™ 2150cn Color Printer.

One of the features of the Dell Printer Configuration Web Tool is E-Mail

Alert Setup, which sends e-mail to you or the key operator when the printer

needs supplies or intervention.
