Understanding the Printer Menus 319

Paper Size

mm series

A4

*1

A5

B5

Letter

Folio

Legal

Executive

Envelope #10

Monarch

Monarch LEF

DL

DL LEF

C5

Custom Size

inch series Letter

*1

Folio

Legal

A4

A5

B5

Executive

Envelope #10

Monarch

Monarch LEF

DL

DL LEF

C5

Custom Size
