Right-Side Bottom Panel 121
25
Right-Side Bottom Panel
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
3
Remove the drive-bay shroud. See "Removing the Drive-Bay Shroud" on
page 47.
4
Remove the hard-drive fan assembly. See "Follow the steps in "After
Working Inside Your Computer" on page 15." on page 69.
5
Remove the power-supply unit. See "Removing the Power-Supply Unit" on
page 83.
6
Remove the right-side top panel. See "Removing the Right-Side Bottom
Panel" on page 121.
7
Remove the right lighting-board. See "Removing the Right Lighting-
Board" on page 117.
8
Remove the right-side middle panel. See "Removing the Right-Side
Middle Panel" on page 113.
Removing the Right-Side Bottom Panel
1
Remove the screws that secure the right-side bottom panel to the chassis.
book.book Page 121 Wednesday, May 16, 2012 2:37 PM
