PCI Shroud 45
7
PCI Shroud
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
Opening the PCI Shroud
1
Press the shroud-release button and rotate the PCI shroud away from the
chassis.
book.book Page 45 Wednesday, May 16, 2012 2:37 PM
