Top Vent 125
26
Top Vent
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Remove the memory fan. See "Removing the Memory Fan" on page 67.
3
Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
4
Remove the drive-bay shroud. See "Removing the Drive-Bay Shroud" on
page 47.
5
Remove the top lighting-board. See "Removing the Top Lighting-Board"
on page 103.
6
Remove the system board. See "Removing the System-Board Assembly" on
page 95.
7
Remove the right-side top panel. See "Removing the Right-Side Top
Panel" on page 107.
Removing the Top Vent
1
Remove the screws that secure the top vent to the chassis.
book.book Page 125 Wednesday, May 16, 2012 2:37 PM
