Dell Alienware Aurora R4 - Replacing the Memory Fan; Postrequisites

68 Memory Fan
Replacing the Memory Fan
1 Align the tabs on the memory fan with the slots on the computer chassis
and slide the fan until it snaps into position.
2 Connect the memory fan cable to the MEM_FAN connector on the top
lighting-board.
Postrequisites
1 Replace the left side-panel. See "Replacing the Left Side-Panel" on
page 27.
1 memory fan 2 tab
3 memory-fan cable 4 top lighting-board
1
3
2
4
