Drive-Bay Shroud 47
8
Drive-Bay Shroud
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Open the PCI shroud. See "Removing the Drive-Bay Shroud" on page 47.
Removing the Drive-Bay Shroud
NOTE: Be careful not to damage the cable connected to the drive-bay shroud
while sliding the drive-bay shroud.
1
Press the tabs and slide the drive-bay shroud towards the back of the
chassis.
2
Gently turn the drive-bay shroud over and place it on the chassis.
book.book Page 47 Wednesday, May 16, 2012 2:37 PM
