Memory Module(s) 65
CAUTION: To avoid damage to the memory module, first insert the end away from
the securing clip and then insert the end near the securing clip.
2
Insert the memory module into the memory-module connector until the
memory module snaps into position and the securing clip locks in place.
1 cutouts (2) 2 memory module
3 notch 4 tab
1 securing clip (snapped in position)
book.book Page 65 Wednesday, May 16, 2012 2:37 PM
