*1
This item is available only when the self-signed certificate has been generated.
*2
This item is effective only when connected via SSL/TLS (https). Only the administrator is allowed to display the pages.
IPsec
Purpose:
To specify the Security Architecture settings for Internet Protocol (IPsec) for encrypted communication to the
printer.
Va lu e s:
IPsec Settings Protocol Select the check box to enable the protocol.
Pre-Shared Key Sets a shared key. Up to 255 alphanumeric characters, periods, and
hyphens can be used.
Re-enter Pre-Shared Key Enters the shared key again to confirm it.
Device Certificate Displays the device certificate.
IKE SA Lifetime Sets the lifetime for IKE SA from 5 to 28,800 minutes.
IPsec SA Lifetime Sets the lifetime for IPsec SA from 5 to 2,880 minutes.
DH Group Sets the DH group.
PFS Select the check box to enable the PFS setting.
Remote peers IPv4 address Sets the IP address to connect to.
Remote peers IPv6 address Sets the IP address to connect to.
Non IPsec communication Allows communication with a device which does not support IPsec.
policy
NOTE: If IPsec is enabled with incorrect settings, you must disable it using the IPsec menu on the operator panel.
802.1x
Purpose:
To specify the settings for IEEE 802.1x authentication for encrypted communication to the printer.
Va lu e s:
Configure 802.1x Enable IEEE 802.1x Select the check box to enable IEEE 802.1x authentication.
Authentication Method EAP-MD5 Selects the authentication method to use for IEEE
802.1x authentication.
EAP-MS-
CHAPv2
PEAP/MS-
CHAPv2
Login Name: (Device
Name)
Sets the login name (device name) for IEEE 802.1x authentication using
up to 128 alphanumeric characters.
Password Sets the login password for IEEE 802.1x authentication using up to 128
alphanumeric characters.
Re-enter Password Confirms the set login password.
Certificate Validation Select the check box to enable Certificate Validation.
Dell™ Printer Configuration Web Tool
142
