Page #326 background imageLoading...
Page #326 background image
Problem Action
Print media misfeeds or multiple feeds Ensure that the print media you are using meets the specifications for your printer.
occur. See "Supported Paper Types" for more information.
Fan the print media before loading it.
Ensure that the print media is loaded correctly.
Ensure that the width and length guides of the print media sources are adjusted
correctly.
Ensure that tray1, the optional 550-sheet feeder (tray2), or the multi-purpose
feeder (MPF) unit is securely inserted.
Do not overload tray1, the optional 550-sheet feeder, or the MPF.
Do not force print media into the MPF when you load it; otherwise, it may skew or
buckle.
Ensure that the print media is not curled.
Face the recommended print side up. See "Loading Print Media in Tray1 and the
Optional 550-Sheet Feeder" for more information.
Turn the print media over or around and try printing again to see if feeding
improves.
Do not mix print media types.
Do not mix reams of print media.
Remove the top and bottom curled sheets of a ream before loading the print
media.
Load print media only when tray1, the optional 550-sheet feeder, or the MPF is
empty.
Wipe the retard rollers in tray1, the optional 550-sheet feeder, or the MPF with a
cloth moistened with water.
The envelope is creased after printed. Make sure that the envelope is loaded in the MPF as instructed in "Loading an
Envelope in the MPF."
Page breaks in unexpected places. Increase the value for Time-Out using the operator panel, the Tool Box, or Dell™
Printer Configuration Web Tool.
Print media does not stack neatly in the Turn the print media stack over in tray1 or the MPF.
output tray.
Cannot print from tray1 or the optional 550- Load the print media into the MPF.
sheet feeder because the print media in
tray1 or the optional 550-sheet feeder is
curled.
Print Quality Problems
NOTE: Some of the following procedures that use the Tool Box can also be performed using the operator panel or Dell Printer
Configuration Web Tool. For information on how to use the operator panel and Dell Printer Configuration Web Tool, see
"Understanding the Printer Menus" and "Dell™ Printer Configuration Web Tool."
The output is too light
Toner smears or print comes off
Random spots/Blurred images
The entire output is blank
Streaks appear on the output
Part or the entire output is black
Troubleshooting Guide 324

Table of Contents

Other manuals for Dell C2660dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell C2660dn and is the answer not in the manual?

Dell C2660dn Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Duplex printing modeAuto
Print speed (black, normal quality, A4/US Letter)27 ppm
Duplex print speed (black, normal quality, A4/US Letter)18 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle50000 pages per month
Recommended duty cycle750 - 3500 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 6, PostScript 3
Paper input typePaper tray
Total input capacity400 sheets
Total output capacity250 sheets
Maximum input capacity950 sheets
Envelopes sizes10, C5, DL, Monarch
Maximum print size216 x 356 mm
Paper tray media typesCoated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight60 - 216 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)A4, A5
ISO B-series sizes (B0...B9)B5
ISO C-series sizes (C0...C9)C5
Maximum ISO A-series paper sizeA4
Wi-FiNo
Security algorithmsSSL/TLS
Mobile printing technologiesNot supported
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity5
Noise level (idle)25.5 dB
Maximum internal memory- MB
Sound pressure level (printing)53 dB
DisplayLCD
CertificationGS, RoHS, WEEE, ErP Lot 6
Product colorBlack
Display number of lines4 lines
AC input voltage230 V
Power consumption (printing)- W
Sustainability certificatesBlue Angel, ENERGY STAR
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supportedRedHat EL Linux 5.0, SuSE Linux 10, SuSE Linux 11
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Package depth686 mm
Package width570 mm
Package height526 mm
Package weight30500 g
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth485 mm
Width439 mm
Height379 mm
