LETTERHEAD

LETTERHEAD

Print media source Print side Page orientation

Tray1 and optional 550-sheet Face down Letterhead enters the printer

feeder last

MPF Face down Letterhead enters the printer

last

Loading Print Media in the MPF

1

Gently pull open the MPF cover.

Loading Print Media 208
