4
Press the button until
TCP/IP
is highlighted, and then press the
(Set)
button.
5
Press the button until
IPv4
is highlighted, and then press the
(Set)
button.
6
Press the button until
Get IP Address
is highlighted, and then press the
(Set)
button.
7
Press the button until
Panel
is highlighted, and then press the
(Set)
button.
NOTE: If the message This Setting Becomes Effective after Restart is displayed, press the
(Back)
button.
8
Press the
(Back)
button.
9
Press the button until
IP Address
is highlighted, and then press the
(Set)
button.
The cursor is located at the first octet of the IP address.
10
Use the number pad to enter the first octet of the IP address, and then Press the button.
The cursor moves to the next digit.
NOTE: You can only enter one octet at a time and must press the button after entering each octet.
11
Enter the rest of the octets, and then press the
(Set)
button.
NOTE: If the message This Setting Becomes Effective after Restart is displayed, press the
(Back)
button.
12
Press the
(Back)
button.
13
Press the button until
Subnet Mask
is highlighted, and then press the
(Set)
button.
14
Repeat steps 11 and 12 to set Subnet Mask.
NOTE: If the message This Setting Becomes Effective after Restart is displayed, press the
(Back)
button.
15
Press the
(Back)
button.
16
Press the button until
Gateway Address
is highlighted, and then press the
(Set)
button.
17
Repeat steps 11 and 12 to set the Gateway Address.
18
Turn off the printer and then turn it on again.
When Using the Tool Box
1
Click
Start
All Programs
Dell Printers
Dell C2660dn Color Laser Printer
Tool Box
.
NOTE: For details about starting the Tool Box, see "Starting the Tool Box."
The
Tool Box
opens.
2
Click the
Printer Maintenance
tab.
3
Select
TCP/IP Settings
from the list at the left side of the page.
The
TCP/IP Settings
page appears.
4
Select the mode from
IP Address Mode
, and then enter the values in IP Address, Subnet Mask, and Gateway
Address.
5
Click
Apply New Settings
to take effect.
You can also assign the IP address to the printer when installing the printer drivers with the installer. When you use the
Network Installation
feature, and the
Get IP Address
is set to
AutoIP or DHCP
on the printer, you can set the IP
address from 0.0.0.0 to the desired IP address on the printer selection window.
Setting the IP Address 58
