Installing a Toner Cartridge

1

Unpack a new toner cartridge of the desired color.

2

Shake the new toner cartridge five or six times to distribute the toner evenly.

3

Insert the toner cartridge into the associated cartridge slot, and then push until it stops.

4

Close the front cover.
