Dell C2660dn - Tray 1

To Next Page

To Previous Page

On* Displays a popup message that prompts to set Paper Type and

Paper Size when paper is loaded in the MPF.

This item is available only when MPF Mode is set to Panel Specified.

Tray 1

Purpose:

To specify the paper loaded in tray1.

Va lu e s:

Paper Size A4

mm series A5

Letter

Executive

Folio

Legal

Custom Size

inch series Letter

Executive

Folio

Legal

Custom Size

Paper Type Plain

Plain Thick

Covers

Covers Thick

Coated

Coated Thick

Recycled

Letterhead

Preprinted

Prepunched

Color

Plain S2

Color S2

Plain Thick S2

Recycled S2
