Dell C2660dn User Manual

Operator Panel
Auto SSID Setup
1 Press the (Menu) button.
2 Press the button until Admin Settings is highlighted, and then press the (Set) button.
3 Press the button until Network is highlighted, and then press the (Set) button.
4 Press the button until Wireless is highlighted, and then press the ( Set ) button.
5 Press the button until Wireless Setup is highlighted, and then press the (Set) button.
The printer automatically searches the access points on wireless network.
6 Press the button until the desired access point is highlighted, and then press the (Set) button.
If the desired access point does not appear, go to "Manual SSID Setup."
NOTE: Some hidden SSID may not be displayed. If the SSID is not detected turn on SSID broadcast from the router.
7 Enter the WEP key or pass phrase.
When the encryption type of the selected access point is WEP in step 6:
• Enter the WEP key, and then press the
(Set) button.
When the encryption type of the selected access point is WPA, WPA2 or Mixed in step 6:
• Enter the pass phrase, and then press the
(Set) button.
8 The Restart System screen appears.
9 Turn off the printer, and turn it on again to apply the settings.
Wireless LAN connection setting is complete.
Manual SSID Setup
1 Press the (Menu) button.
2 Press the button until Admin Settings is highlighted, and then press the (Set) button.
3 Press the button until Network is highlighted, and then press the (Set) button.
4 Press the button until Wireless is highlighted, and then press the ( Set ) button.
5 Press the button until Wireless Setup is highlighted, and then press the (Set) button.
6 Press the button until Manual Setup is highlighted, and then press the (Set) button.
7 Enter the SSID, and then press the (Set) button.
8 Select the network mode from Infrastructure and Ad-hoc depending on your environment, and then press
the
(Set) button.
If you select
Infrastructure , proceed to step 9.
If you select
Ad-hoc , proceed to step 10.
Installing Optional Accessories 47

Dell C2660dn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	750 - 3500 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 6, PostScript 3
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	10, C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	60 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	SSL/TLS
Mobile printing technologies	Not supported
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	5
Noise level (idle)	25.5 dB
Maximum internal memory	- MB
Sound pressure level (printing)	53 dB
Display	LCD
Certification	GS, RoHS, WEEE, ErP Lot 6
Product color	Black
Display number of lines	4 lines
AC input voltage	230 V
Power consumption (printing)	- W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0, SuSE Linux 10, SuSE Linux 11
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Package depth	686 mm
Package width	570 mm
Package height	526 mm
Package weight	30500 g
Cables included	AC

Weight and Dimensions

Depth	485 mm
Width	439 mm
Height	379 mm
