Dell C2660dn User Manual

D:\Drivers\XPS\Win_7Vista\XPS-V3_C2660.zip (where D is the drive letter of the optical drive)
2 Click Start → Devices and Printers .
3 Click Add a printer .
4 Click Add a network , wireless or Bluetooth printer .
5 Select printer or click The printer that I want isn't listed .
NOTE: When you click The printer that I want isn't listed, Find a printer by name or TCP/IP address screen appears. Find your
printer on the screen.
If the User Account Control dialog box appears, click Continue .
NOTE: If you are an administrator on the computer, click Continue; otherwise, contact your administrator to continue the
desired action.
6 Click Have Disk to display the Install From Disk dialog box.
7 Click Browse , and then select the extracted folder in step 1.
8 Click OK .
9 Select your printer name and click Next .
10 To change the printer name, enter the printer name in the Printer name box, and then click Next .
To use this printer as the default printer, select the
Set as the default printer check box, and then click Next .
11 If you do not share your printer, select Do not share this printer . If you share your printer, select Share this printer
so that others on your network can find and use it
.
12 Click Next .
Installation starts.
13 As the driver installation is completed, click Print a test page to print a test page.
14 Click Finish .
Windows 7 or Windows 7 64-bit Edition
1
Extract the following zip file to your desired location.
D:\Drivers\XPS\Win_7Vista\XPS-V3_C2660.zip (where D is the drive letter of the optical drive)
2 Click Start → Devices and Printers .
3 Click Add a printer .
4 Click Add a network , wireless or Bluetooth printer .
5 Select printer or click The printer that I want isn't listed .
When you select your printer, go to step 8.
When you click
The printer that I want isn't listed , go to step 6.
6 Select Add a printer using a TCP/IP address or host name , and then click Next .
7 Select TCP/IP Device from Device type , and enter the IP address for Hostname or IP address , and then click
Next .
If the
User Account Control dialog box appears, click Yes .
NOTE: If you are an administrator on the computer, click Yes; otherwise, contact your administrator to continue the desired
action.
8 Click Have Disk to display the Install From Disk dialog box.
9 Click Browse , and then select the extracted folder in step 1.
10 Click OK .
Installing Printer Drivers on Windows
®
Computers 71

Dell C2660dn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	750 - 3500 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 6, PostScript 3
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	10, C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	60 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	SSL/TLS
Mobile printing technologies	Not supported
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	5
Noise level (idle)	25.5 dB
Maximum internal memory	- MB
Sound pressure level (printing)	53 dB
Display	LCD
Certification	GS, RoHS, WEEE, ErP Lot 6
Product color	Black
Display number of lines	4 lines
AC input voltage	230 V
Power consumption (printing)	- W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0, SuSE Linux 10, SuSE Linux 11
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Package depth	686 mm
Package width	570 mm
Package height	526 mm
Package weight	30500 g
Cables included	AC

Weight and Dimensions

Depth	485 mm
Width	439 mm
Height	379 mm
