Table 43. EX300 2U PDU cabling (continued)

2U PDU cabling PS1 outlet numbers PS2 outlet numbers Line cord per zone (Single phase)

Zone B Zone A

Black cables Gray cables

FE 2 13 13 1

FE 1 1 1 1

Service Tray and Light Bar 8 8 2

BE 2 14 14 1

BE 1 2 2 1

Node 7 7 7 2

Node 6 6 6 2

Node 5 5 5 2

Node 4 16 16 1

Node 3 15 15 1

Node 2 4 4 1

Node 1 3 3 1

In the following diagrams, the switches plug into the front of the rack and route through the rails to the rear.

EX300 Platform

103
