Dell ECS EX Series User Manual

Table 51. EX3000S PDU cabling
PDU cabling Node A - PS1
outlet numbers
Node A - PS2
outlet numbers
Switch PS2 outlet
numbers
Switch PS1 outlet
numbers
Line cord number
per zone (single
phase)
Zone B Zone A Zone B Zone A
Black cables Gray cables Black cables Gray cables
FE 2 13 13 1
FE 1 1 1 1
Chassis 8 22 22 3
Chassis 7 11 11 3
Chassis 6 9 9 3
Chassis 5 18 18 2
BE 2 14 14 1
BE 1 2 2 1
Service tray 8 2
Light Bar 20 2
Chassis 4 7 7 2
Chassis 3 5 5 2
Chassis 2 15 15 1
Chassis 1 3 3 1
Table 52. EX3000D PDU cabling
PDU cabling Node B -
PS1 outlet
numbers
Node B -
PS2 outlet
numbers
Node A -
PS1 outlet
numbers
Node A -
PS2 outlet
numbers
Switch PS2
outlet
numbers
Switch PS1
outlet
numbers
Line cord
number per
zone (single
phase)
Zone B Zone A Zone B Zone A Zone B Zone A
Black cables Gray cables Black cables Gray cables Black cables Gray cables
FE 2 13 13 1
FE 1 1 1 1
Chassis 8 22 23 23 22 3
Chassis 7 11 21 21 11 3
Chassis 6 9 10 10 9 3
Chassis 5 18 19 19 18 2
BE 2 14 14 1
BE 1 2 2 1
Service tray 8 2
Light Bar 20 2
Chassis 4 7 17 17 7 2
Chassis 3 5 6 6 5 2
Chassis 2 15 16 16 15 1
Chassis 1 3 4 4 3 1
EX3000 Platform 135
